FX8000 Automotive OBD2 Scanner Code Reader Car All System Oil EPB ABS Diagnostic Tool

Power Mode:USB

Operating Voltage:≤36V

Battery Capacity (mAh):0

Item ID:VV27170

●Full System Diagnostic & Scan: This car obd2 scanner is capable of reading and clearing trouble codes of all major systems , including Engine, Airbag/SRS, Transmission, ABS, SAS, Air Conditioning, ACC, Audio, Headlight ,Center Lock, ESP,Suspension failures, ect. It also can temporarily start and control your vehicle’s systems for active testing, provide you with accurate data results about troubleshoot and diagnostic problems

●Advanced Features:ABS Bleeding; SAS, Steering Angle Sensor Calibration; BRT, Battery Replacement; EPB, Electronic ParBrake; Oil Service Reset; TBA/TPS, Throttle Body Alignment;
● Universal OBDII/EOBD Check: obd2 diagnostic code reader provides comprehensive OBDII diagnostics for global OBDII/EOBD vehicles, reads and clear codes, turns off MILs, requests and records live sensor data, ect. except live data reading. In addition, it supports all 10 OBDII test modes, includs the mode 6 test.

Multi special function meet your need
In addition to amazing & powerful diagnostic function, FX8000 also features various service functions. The most commonly performed service functions contain：
1. Oil Lamp Reset Service Allows you to perform reset for a calculation of Engine Oil Life system once changed the oil.
2. EPB Electronic Park Brake Reset It is important in the maintenance of electronic brasystem's safety and efficiency.

3. BAT battery service Allows the scan tool to evaluate the battery charstate, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle.
4. SAS Steering Angel Sensor Reset Helps clear the fault steering angle sensor memories and plays an important role in the steering angle sensor calibration.
5. ABS Bleeding ABS brake bleeding to get a firm brake pad after air exhaustion after repair ABS pump system.

6. Throttle Adaptation The throttle body is a tube containing a pivoting flat valve (butterfly) that is used to control the amount of air entering an engine. In an electronically fuel injected car, a throttle position sensor and air flow sensor communicate with the computer, which supplies the corresponding amount of fuel needed at the injectors. It must need re-learning throttle sensor position after clearing or repair.

Full 10 Mode OBDII/EOBD/JOBD Car Diagnostics Functions:
This scanner supports all 10 test modes for OBD-II cars which are . The table below describes the purpose of each mode of operation:
1. Reading Codes: Show the detailed description of the Diagnostic Trouble Code (DTCs)
2. Erasing Codes & Reset: Turns off Check Engine Light (MIL), clears codes and resets monitors.
3. Data Stream: Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze frame data.

4. I/M Readiness Status: Shows whether the various emissions-related systems on the vehicle are operating properly and are ready for inspection and maintenance testing.
5. Read Live Data Stream: Show the information of continuous data stream from a vehicle in live graphic (waveform) display.
6. View Freeze Frame Data: Check the certain vehicle conditions which are recorded by the on-board computer at the time the emission-related fault occurs.

7. O2 Sensor Test: Allows retrieval and viewing of O2 sensor monitor test results for the most recently performed tests from the vehicle’s on-board computer.
8. On-Board Monitor Test: Retrieves and displays test results for emission-related powertrain components and systems.
9. Read Vehicle Information:Display the information such as VIN (Vehicle Identification Number), CID (Calibration ID) and CVN (Calibration verification number), etc.

10. Component Test: Certain vehicle components can be actuated by commands sent from the scanner to test their operability.

Support Languages
English, French, Spanish, Russian, Japanese, German, Italian, Portuguese, Korean.
